RICH SOLAR

BRAVO AIR 30 | 30A Flush Mount PWM Solar Charge Controller | Bluetooth & Multi-Protection | Premium 12V 30A Controller for RVs, Trailers, Campers, Vans & Boats

SKU RS-PWM30PF
$79.99
$79.99

RICH SOLAR

BRAVO AIR 30 | 30A Flush Mount PWM Solar Charge Controller | Bluetooth & Multi-Protection | Premium 12V 30A Controller for RVs, Trailers, Campers, Vans & Boats

SKU RS-PWM30PF
$79.99
BRAVO AIR 30 | 30A Flush Mount PWM Solar Charge Controller | Bluetooth & Multi-Protection | Premium 12V 30A Controller for RVs, Trailers, Campers, Vans & Boats

Frequently Bought Together

Total price$7,668.98

Product Description

Features

Smart Charging Control

  • PWM + MOSFET for efficient, stable output
  • Intelligent multi-stage charging
  • Auto BMS activation for lithium batteries
  • Built-in Bluetooth for remote monitoring
  • Battery type selection, with real-time display and LED status indicators

Full Electrical Protection

  • Protection against: over-voltage, short circuit, reverse polarity, and over-temperature
  • Spark-free safety
  • Fully certified: ETL, CE, EMC, FCC, and RoHS

Broad Battery Compatibility

  • Supports: Flooded, AGM, GEL, Calcium, LiFePO4
  • Optional external temperature sensor (BTS) for temp-compensated charging

Specifications

Electrical Parameters

  • Rated solar panel amps: Max. 30 A
  • Normal input solar cell array voltage: Max. 5~22 VDC
  • Maximum solar cell array voltage (output has no load): Max. 25 VDC
  • The controller's lowest operating voltage at the solar or battery side: Min. 8 VDC
  • Standby current consumption at night: Max. 10 mA
  • Maximum voltage drop – Solar panel to battery: Max. 0.25 VDC

Protection

  • Against reverse polarity or short circuit at the panel or battery
  • Over temperature protection during charging: 185°F / 85°C

Environmental Characteristics

  • Operating temperature: -13 ~ 122°F / -25 ~ 50°C
  • Storage temperature: -40 ~ 185°F / -40 ~ 85°C
  • Operating humidity range: 0–85% RH

Physical Parameters

  • Controller material: Plastic (PC)
  • Power terminal max. wire size: #8 AWG stranded – 0.2 in²
  • Power terminal torque: 6.2–7.1 in-lb (0.7–0.8 N·m)
  • Mounting: Vertical wall mounting
  • IP grade: IP22
